In plastic compounding operations, designing an efficient pneumatic conveying and feeding system for calcium carbonate (CaCO₃) powder is essential. Correctly selecting the optimal pneumatic transport and feeding solutions can significantly improve ROI for mixing plants because multiple flow-affecting variables are at play.
Why Calcium Carbonate Matters
Calcium carbonate is one of the most popular mineral fillers in plastics. It is tunable via grinding and particle sizing and effectively reduces surface energy, increases opacity and gloss, and, when milled finely, enhances impact strength and flexural modulus. Calcium carbonate is used across various thermoplastics:
Polypropylene composites benefit from improved hardness and high-temperature tolerance.
PVC compounds—from flexible items like gloves and cable insulation to rigid profiles like piping—rely on CaCO₃ for performance and cost efficiency.
1. Pneumatic Conveying of Calcium Carbonate
Factors affecting powder flow—such as particle shape, size distribution, surface roughness, hardness, and bulk density—must be carefully assessed. Since properties vary by source and production method, customized pneumatic systems are necessary. Conduct lab tests to analyze powder behaviors and inform system design.
Typical pneumatic systems include:
1. Power supply (vacuum or pressure)
2. Conveying lines
3. Feeding devices
4. Material-gas separation units
5. Control systems
Feeding Equipment
Light and free-flowing CaCO₃ may flood transfer lines when discharged from a hopper. Use rotary valves to meter material consistently. For sticky grades that clog, opt for blow-through rotary valves that keep blades clear via airflow. Installing fluidizing cones in hoppers also aids flow.
Conveying Lines
Clogs and material buildup are common issues. Rigid piping suits most CaCO₃ types, but flexible tubing helps dislodge powder sticking to pipe walls. A flush valve in vacuum systems clears residues by shutting off vacuum and releasing pressure waves.
Material-Gas Separation
Sticky CaCO₃ clogs filters easily. Use bag filters instead of cartridge filters, and consider PTFE media for highly adhesive grades. Alternative solutions include steep hopper angles and flow aids like liners or vibrators to ensure complete discharge.
2. Calcium Carbonate Feeding
Two variables determine your feeding system choice:
Filler properties: particle size, shape, permeability, bulk density, and repose angle
Required feed rate
Loss-in-Weight (LIW) Feeders
These sealed feeders offer precise control, dust containment, and high accuracy. You can customize hopper size and screw type according to flow characteristics and required throughput.
Volumetric vs. Gravimetric Feeders
Volumetric feeders deliver constant volume at low cost; best for stable bulk-density materials with low-precision needs.
Gravimetric (weight-based) feeders deliver consistent mass flow and include feedback systems to adjust for density changes.
Hopper Design
Choose a hopper shape (cylindrical, symmetric, or offset) and volume (1 L to several hundred L) based on refill frequency and available space. Aim to refill 12 times per hour, maintaining material at ≤80% full. Calculate hopper size by using:
Hopper volume = Flow rate / (Bulk Density × 0.8 × 12)
Avoid oversized hoppers to reduce risk of rod formation and bridging and limit material compaction due to particle interactions.
Feeder Screw Type
Free-flowing CaCO₃ works with a single-screw feeder, but twin-screw feeders often offer better reliability. Choose screw geometry (flights, grooves) based on material flow and filler rate. Counter-rotating twin screws are self-cleaning and prevent bridging and overfeeding.
Weigh Scale Systems
Weigh scales range from small tabletop units to large triple-beam weigh hoppers and help monitor and maintain feed accuracy.
Proper handling of powdered calcium carbonate requires tailored pneumatic and feeding solutions. By optimizing hopper design, choosing suitable rotary valves, screw feeders, and scale systems, and balancing cost with performance needs, you can maintain consistent feed quality and minimize downtime in compounding lines.
