Choosing The Right Carrier for Color Masterbatches in TPE Pelletizing

In TPE (Thermoplastic Elastomer) pelletizing, the choice of color masterbatch plays a critical role in ensuring uniform color distribution, stable performance, and cost control. Selecting an appropriate masterbatch carrier depends on the TPE's application, performance requirements, and processing conditions.

I. Key Factors in Choosing Masterbatch Carriers

1. Compatibility with TPE Matrix

The carrier must have a similar chemical structure to the TPE base to prevent poor dispersion or blooming.

2. Matching Processing Temperatures

The melting point of the carrier should align with the TPE processing range to ensure smooth dispersion during pelletizing.

3. Impact on TPE Properties

The carrier should not significantly compromise key TPE attributes such as elasticity, weather resistance, or food safety.

4. Cost and Processing Efficiency

Select carriers that meet performance needs while minimizing cost and maximizing processing efficiency.

II. Recommended Masterbatch Carriers by TPE Application

1. Toys, Stationery, Soft Overmolded Part

Recommended Carrier: LDPE (Low-Density Polyethylene)

Advantages:

• Good compatibility with non-polar TPEs

• Ensures even pigment dispersion

• Low cost and soft texture, preserving TPE's flexibility

Note: Keep LDPE dosage in check to avoid mechanical property loss; use UV stabilizers for weather-resistance requirements.

2. Automotive Interiors, Grips for Tools or Handles

Recommended Carrier: PP (Polypropylene)

Advantages:

• High heat resistance (up to 120°C)

• Improves hardness and rigidity

• Good compatibility with PP-based TPEs

Note: PP has poor low-temperature toughness; control processing temperatures between 160–175°C to avoid decomposition.

3. Transparent Tubes, Medical Catheters

Recommended Carrier: PS (Polystyrene)

Advantages:

• High transparency

• Good flowability for even pigment dispersion

• Suitable for low-temp processing (<200°C)

Note: Poor heat/weather resistance—consider modifications; ensure PS and pigments meet health standards (e.g., FDA).

4. Soft Toys, Yoga Mats

Recommended Carrier: EVA (Ethylene Vinyl Acetate)

Advantages:

• Enhances softness and rebound

• VA groups improve pigment dispersion

• Decent cold resistance for winter use

Note: EVA may degrade under water or outdoor exposure—use water/UV stabilizers; select appropriate VA content (15–28%).

5. High-end Food-Grade or Weather-Resistant TPE

Recommended Carrier: SEBS (Styrene-Ethylene-Butylene-Styrene)

Advantages:

• Excellent compatibility with TPE

• Meets food-grade safety requirements

• Outstanding weather resistance with additives

Note: SEBS-based masterbatches are costly—consider product positioning and certification needs (e.g., FDA, LFGB).

III. Additional Considerations

1. Pigment and Carrier Matching

Choose pigment types (organic/inorganic) with suitable lightfastness and migration resistance based on application needs.

2. Masterbatch Concentration and Dosage

High-concentration masterbatches reduce carrier impact on TPE, but must ensure good dispersion; determine dosage through testing.

3. Processing Optimization

Adjust processing parameters (temperature, screw speed) for different carriers—for instance, stay below 200°C for PS carriers and raise temperature for PP carriers to ensure melting and dispersion.
