Masterbatch plays a crucial role in plastic coloration and modification. However, various processing issues such as high carbon black loading, surface defects, poor dispersion, density testing difficulties, and film discoloration can significantly impact production quality. This article compiles real-world Q&A on masterbatch processing to help manufacturers troubleshoot common problems efficiently.
1. How to Produce PP Masterbatch with Over 40% Carbon Black Content Without Strand Breakage?
Problem:
High-carbon black PP masterbatch (40%+) often causes strand breakage and severe contamination during production.
Technical Solutions
Carbon black is difficult to disperse. With a conventional twin-screw extruder, content above 30% is challenging.
Solution: Use a two-step pelletizing process, adding carbon black in separate batches.
Dry processing is dusty and unclean.
Solution: If possible, use an internal mixer (kneader). Carbon black loading can reach 50% with much cleaner operation.
Consider switching to hot-cut pelletizing, which eliminates strand-breaking problems.
Formulation Improvements
Use carrier resins with high melt-flow properties.
Combine high-molecular-weight dispersants with standard dispersants.
Consider producing carbon black paste (black masterbatch slurry) to significantly reduce dust.
2. Why Does ASA Co-Extruded Surface Develop Small Pinholes After Polishing?
Possible Causes
Poor material blending or dispersion
Incompatibility issues
Moisture in the material
Solutions
Thoroughly dry the ASA and color masterbatch
Adjust co-extrusion temperature
Avoid extruding layers that are too thin
Ensure proper extrusion procedures
Prevent contamination from calcium carbonate
3. Why Is Antioxidant Usage So Low in Masterbatch? Can We Make Weather-Resistant Grades?
Masterbatch typically uses only small amounts of antioxidants and lubricants. Without sufficient antioxidant protection, high shear can cause:
Yellowing
Polymer degradation
Poor strand formation
When Antioxidants Are Necessary
Outdoor applications → add both UV stabilizer + antioxidant
End-users requiring anti-aging properties
Engineering plastics such as PA, ABS → antioxidants are essential
Fiber-grade masterbatch → always requires antioxidants
Cost is the primary reason antioxidants are minimized, but performance requirements determine the actual dosage.
4. How to Accurately Measure the Density of Masterbatch?
Recommended Density Testing Methods
1.Density Bottle Method
Very accurate but sensitive to air bubbles and temperature.
2.Density Gradient Column
Accurate and simple to operate.
3.Electronic Densimeter (Archimedes Principle)
Fast, suitable for pellets, accuracy up to 4 decimal places.
5. How to Select Carrier Resins for Masterbatch Production?
Carrier Resin Options
Universal carriers: PE, EVA, PP, PVC
Specified carriers:
ABS masterbatch → ABS carrier
SAN masterbatch → typically not SAN because of cost
Fiber masterbatch → special designated carriers only
Carrier-free masterbatch → wax-based
Disadvantages of Universal Masterbatch
Poor color predictability
Negative impact on mechanical properties
Higher cost due to high heat-resistant pigments
Best practice:
Use the same resin as the end-product whenever performance requirements are high.
6. Additives that Improve Compatibility Between Masterbatch and Resin
Common Compatibilizing Additives
Coupling Agents:
Chemically bond pigments to the polymer chain.
Compatibilizers:
One segment compatible with pigment, the other with resin—similar to surfactant behavior.
Silicone-based Additives (e.g., Tegonler):
Provide both compatibility improvement and lubrication.
Tip:
In some cases, compatibilizers themselves can be used as carrier resins.
7. ABS Extrusion Sheet Has Undispersed Color Spots. How to Solve It?
Causes & Solutions
1.Poor pigment dispersion
Use a twin-screw extruder with higher shear
Add silicone additives for better dispersion
Choose easily dispersible pigments
2.Low-flow carrier resin
Replace with higher MFR carrier resin
Use mixture carrier: 50% ABS + 50% SAN with lubricants (EBS)
3.Titanium dioxide issues
Use rutile-type TiO₂ (better flow)
Ensure equipment cleanliness
Add a finer filter screen at the die
4.Moisture
Ensure proper drying of raw materials
8. Why Do White Films Turn Yellow or Even Red After Storage?
Diagnosis Method
Blow two types of films:
Transparent (no masterbatch)
Milky white (with masterbatch)
If only the milky white film yellows → TiO₂ issue
If both yellow → LDPE resin or antioxidant issue
Causes of Yellowing
Anatase-type titanium dioxide → prone to yellowing
Unstable phenolic antioxidants (oxidize to quinones)
Moisture
Additives contamination
Impure TiO₂
Improper drying
Poor processing conditions
Solutions
Use imported rutile-type TiO₂, e.g., KONUSS 2220
Add auxiliary antioxidants (e.g., AO-168)
Ensure CaCO₃ does not catalyze oxidation
Control processing temperature and environment
Add metal deactivators if necessary
Causes of Red Discoloration
Quinone formation from phenolic antioxidants
Moisture in resin or masterbatch
PE resin with unstable antioxidant packages
Solution: Add stearates to minimize red shift
Conclusion
Masterbatch processing involves a wide range of formulation and processing challenges—from dispersion quality and strand stability to polymer compatibility and color stability. By applying correct equipment choices, optimized formulations, and scientific testing methods, manufacturers can significantly enhance product performance, consistency, and production efficiency.
